TTLOCK ROTOR LITE
Electronic motor for Euro-cylinder rotation with APP TTLOCK is an innovative and simple solution on the electronic locks types, which will provide a high level of security, control and comfort of access using previously installed mechanical locks.
WARNING - due to the low-power design of the motor and batteries, this lock is not suitable for installation on big locking systems with deviators and a large number of dead-bolts. Before installing this motor, make sure that the locking mechanisms run smoothly.
TTLOCK wireless remote control.
Up to 15 radio remotes with unique ID can be connected to the lock, which transmit encoded digital signal via BLE technology. This technology eliminates interception and duplication of lock opening commands.
Each remote control is given a unique name and can set an individual schedule when the user can open the door .
All opening events are recorded in the lock memory and transfer to app.
TTLOCK wireless remote keypad.
A wireless keypad can be connected to the lock, which transmits the entered code at distances of up to 10m.
Access codes are set via the standard TTLOCK application menu, which allows remote creation of unique access codes for a limited period of time, time-limited access codes, scheduled access codes, one-time passwords and customisable passwords for comfortable access.
Product Parameters
| TYPE | Smart Motorized Cylinder |
| NAME | ROTATOR |
| UNLOCK WAYS | Wireless keypad ( not included ), BLE Remote control ( not included ), APP WiFi ( need GATE ), APP Bluetooth, Mechanical Key |
| LOCK WAYS | AUTO ( door sensor ), press buttons on keypad, BLE Remote control, APP WiFi ( need GATE ), APP Bluetooth, Mechanical Key |
| MATERIAL MADE | Plastic |
| PROTECTION LEVEL | Indoor use only |
| USER CAPACITY | PASSWORD - 150; REMOTE CONTROL - 16; eKey- no limit |
| DOOR THICKNESS | 40mm~100mm |
| WORKING TEMP | 0℃~50℃ |
| POWER | 6V (4 x АA Batteries) near 500 cycles of open/close |
